It will also help maintain a stable osmotic balance for saltwater applications, which is especially important for small aquariums that are sensitive to continuous fluctuations in salt concentration.
Installation is simple and operation is quiet. A powerful diaphragm pump and dual optical sensor are combined in one package, avoiding a nest of unwanted wires.
Features :
- Integrated with rapid security technology
- Dual optical level sensor with magnetic mounting
- Easily cleanable and reusable pre-filter
- Anti-siphon valve to prevent forward siphoning
- Adjustable sensor cable length
- Simple installation and easy maintenance
Technical characteristics :
Power supply:
Input: 100-240 VAC 50-60 Hz
Output: 12 VDC / 1A
Power cable length: 180 cm
Diaphragm pump:
Suction height: 200 cm
Flow rate: 30 l/h
Maximum mounting thickness:
Sensor: 12.7mm
Support: 3-10mm
Anti-siphon valve:
Anti-siphon pressure: 60 cm
Sensor cable length: 45 cm
Pipe :
Length: 200cm
Inner diameter: 4 mm / Outer diameter: 6.4 mm
Included in the kit:
ATO Nano Smart Controller
The controller includes a dual sensor and a diaphragm pump. The device includes storage space for unnecessary extra wires, allowing for a clean appearance.
Durable and reusable pre-filter
Its ingenious and unique design filters all dirt and contaminants from the tank. Additionally, the user-friendly design of the pre-filter allows for simple installation and maintenance. Its crystal clear body allows users to quickly check its cleanliness. Additionally, the O-ring it contains allows it to work well under high pressure. Another essential feature of this pre-filter is that it can be quickly disassembled for easy maintenance.
Universal electrical adapter
Input: 100-240V ~ 50-60Hz
Output: 12V/1A
The anti-siphon valve
Used to stop a rear siphon and manage the pressure of the front siphon up to 60 cm of water.
How to place Smart ATO Nano?
Hang the device on the wall of the aquarium or pond, connect the hoses and plug in the power supply. The multi-position “hung on the back” installation design is convenient and flexible for rimless or rimless tanks. In addition, the double magnetic sensor, easy to install, can be positioned wherever you want. Adjustable bracket suitable for aquarium glass thickness 3-10mm.
Disassembly is quick and without any screws.
Thanks to its tool-free design, the device is easily assembled or disassembled in minutes. The absence of screws means that there is no risk of pollution caused by rust in the tank!
Simple installation
The sensor's adjustable cable allows for a tidy installation. Hide the unnecessary cable in the storage space located in the body. Two holes on the cover allow the inlet tube to be attached for more flexible installation.
