Continuous operation mode
Thanks to the robust stepper motor and the quality pump head using Pharmed tubing, the DD P1-STP peristaltic pump is suitable for constant 24/7 operation. This makes it ideal for applications where precise volumes of water need to be delivered which are not achievable with standard pumps, especially at lower flow rates.
The precise flow rate is easily set in the app by simply entering the amount you wish to supply and confirming. All adjustments are just as easy, as well as pausing the pump for maintenance and resuming with minimal effort through simple app control. With a flow rate of 1 to 70 ml/min, the P1-STP is suitable for Deltec calcium reactors up to PF601 and NPF509 or NPF512 nitrate reactors.
Dosing mode
In addition to being used as a continuous pump, the pump can also be switched to dosing mode for precise liquid additions. In this setting, not only small additions of up to 0.1ml can be made, but larger additions which, although possible with a standard dosing pump, would normally cause excessive wear due to the long running time.
In dosing mode the P1-STP offers all the control flexibility you would expect from a good quality unit with options to dose on certain days, between set times or even have different dosing schedules at different times over a period of 24 hours. Built-in monitoring can be set up to track how much liquid is left in your containers and show how many days you have left before you need to refill.
Remote App Control via Cloud
The P1-STP is fully app controlled via your smartphone or tablet. The app free download is available in both IOS and Android versions.
Using the Kamoer Remote app, it is possible to choose between connecting the pump via your home router allowing access to the unit from anywhere in the world or using a local connection to connect directly from your mobile device.
Both options will give you full access to the flexible settings of the P1-STP. The app allows to set pump operating mode, pump head calibration, firmware updates (when connected via a home router), dosing schedules or flow rate settings continued. In continuous mode, a maintenance reminder can also be set to remind you when the pump head needs to be replaced and display the time the head has been in service.
Features
- Continuous, manual or automatic dosing modes.
- Suitable for 24/7 continuous use.
- Adjustable flow rates/dosages in continuous or programmable mode.
- Dosing frequency, daily / every “X” days / specific days.
- Up to 24 dosing points per day. Custom dosing period.
- Calculates and displays the liquid remaining in the measuring container.
- Direct drive pump head for greater precision.
- Pharmed BPT Long Life Pump Tube.
- Threaded connections on the pump head for added security.
- Calibration function.
- Battery backup function to keep correct time.
